12N10 MOSFET - описание производителя. Даташиты. Основные параметры и характеристики. Поиск аналога. Справочник

Наименование прибора: 12N10

Тип транзистора: MOSFET

IXFT15N100Q3, N-channel Power MOSFET, IXYS HiperFET™ Q3 Series The IXYS Q3 class of HiperFET™ Power MOSFETs are suitable for both hard switching and resonant mode applications, and offer low gate.

Alibaba.com offers 3,688 mosfet 1000v products. A wide variety of mosfet 1000v options are available to you, such as brand name, type. POWER MOSFET 1000V N-CHANNEL THRU-HOLE TO-254AA. POWER MOSFET THRU-HOLE 1000V N-CHANNEL. 250V N-Channel MOSFET.

Полярность: N

Максимальная рассеиваемая мощность (Pd): 73 W

Предельно допустимое напряжение сток-исток |Uds|: 100 V

Предельно допустимое напряжение затвор-исток |Ugs|: 20 V

Максимально допустимый постоянный ток стока |Id|: 12 A

Максимальная температура канала (Tj): 150 °C

Время нарастания (tr): 7 ns

Выходная емкость (Cd): 90 pf

Сопротивление сток-исток открытого транзистора (Rds): 0.15 Ohm

Тип корпуса: TO-220TO-251TO-252

12N10 Datasheet (PDF)

0.1. mtp12n10e.pdf Size:203K _motorola

MOTOROLAOrder this documentSEMICONDUCTOR TECHNICAL DATAby MTP12N10E/DDesigner's Data SheetMTP12N10ETMOS E-FET.Motorola Preferred DevicePower Field Effect TransistorN Channel Enhan

0.2. mtp12n10erev1a.pdf Size:239K _motorola

MOTOROLAOrder this documentSEMICONDUCTOR TECHNICAL DATAby MTP12N10E/DDesigner's Data SheetMTP12N10ETMOS E-FET.Motorola Preferred DevicePower Field Effect TransistorN Channel Enhan

0.3. php12n10e 1.pdf Size:57K _philips

Philips Semiconductors Product Specification PowerMOS transistor PHP12N10E GENERAL DESCRIPTION QUICK REFERENCE DATAN-channel enhancement mode SYMBOL PARAMETER MAX. UNITfield-effect power transistor in aplastic envelope. The device is VDS Drain-source voltage 100 Vintended for use in Switched Mode ID Drain current (DC) 14 APower Supplies (SMPS), motor Ptot Total power dissipation 7

0.4. phd12n10e 2.pdf Size:61K _philips

Philips Semiconductors Product Specification PowerMOS transistor PHD12N10E GENERAL DESCRIPTION QUICK REFERENCE DATAN-channel enhancement mode SYMBOL PARAMETER MAX. UNITfield-effect power transistor in aplastic envelope suitable for surface VDS Drain-source voltage 100 Vmounting. The device is intended for ID Drain current (DC) 14 Ause in Switched Mode Power Ptot Total power dissip

0.5. rfp12n10l.pdf Size:131K _fairchild_semi

RFP12N10LData Sheet April 200512A, 100V, 0.200 Ohm, Logic Level, FeaturesN-Channel Power MOSFET 12A, 100VThese are N-Channel enhancement mode silicon gate rDS(ON) = 0.200power field effect transistors specifically designed for use Design Optimized for 5V Gate Driveswith logic level (5V) driving sources in applications such as programmable controllers, automotiv

0.6. mtp12n08l mtp12n10l.pdf Size:107K _njs

0.7. rfm12n08l rfm12n10l rfp12n08l.pdf Size:95K _njs

0.8. rfm12n08 rfm12n10 rfp12n08 rfp12n10.pdf Size:94K _njs

0.9. mtm12n10 mtp12n10e.pdf Size:94K _njs

0.10. ixga12n100 ixgp12n100 ixga12n100a ixgp12n100a.pdf Size:51K _ixys

VCES IC25 VCE(sat)IGBTIXGA/IXGP12N100 1000 V 24 A 3.5 VIXGA/IXGP12N100A 1000 V 24 A 4.0 VPreliminary Data SheetTO-220AB (IXGP)Symbol Test Conditions Maximum RatingsVCES TJ = 25C to 150C 1000 VVCGR TJ = 25C to 150C; RGE = 1 MW 1000 VGVGES Continuous 20 VCEVGEM Transient 30 VIC25 TC = 25C24 ATO-263 (IXGA)IC90 TC = 90C12 AICM TC = 25C, 1 ms 48 A

0.11. ixfr10n100q ixfr12n100q.pdf Size:33K _ixys

Advanced Technical InformationVDSS ID25 RDS(on)HiPerFETTM Power MOSFETsIXFR 12N100Q 1000 V 10 A 1.05 WISOPLUS247TM Q CLASSIXFR 10N100Q 1000 V 9 A 1.20 W(Electrically Isolated Back Surface) trr 200 nsN-Channel Enhancement ModeAvalanche Rated, High dV/dtLow Gate Charge and CapacitancesSymbol Test Conditions Maximum Ratings ISOPLUS 247TMVDSS TJ = 25C to 150C 1000 V

0.12. ixgp12n100au1.pdf Size:84K _ixys

VCES IC25 VCE(sat)IGBTIXGA/IXGP12N100U1 1000 V 24 A 3.5 VCombi PackIXGA/IXGP12N100AU1 1000 V 24 A 4.0 VPreliminary Data SheetSymbol Test Conditions Maximum Ratings TO-220AB(IXGP)VCES TJ = 25C to 150C 1000 VVCGR TJ = 25C to 150C; RGE = 1 MW 1000 VGCEVGES Continuous 20 VVGEM Transient 30 VTO-263 AA (IXGA)IC25 TC = 25C24 AIC90 TC = 90C12 AICM TC =

0.13. ixz4df12n100.pdf Size:245K _ixys

IXZ4DF12N100 RF Power MOSFET & DRIVER 1000 Volts Driver / MOSFET Combination 12 A DEIC-515 Driver combined with a DE375-102N12A MOSFET 0.7 Ohms Gate driver matched to MOSFET Features Isolated Substrate - high isolation voltage (>2500V) - excellent thermal transfer - Increased temperature and power cycling capability IXYS advanced Z-MOS process Low RDS(on)

0.14. ixfr10n100f ixfr12n100f.pdf Size:97K _ixys

VDSS ID25 RDS(on)HiPerFETTM Power MOSFETsIXFR 12N100F 1000 V 10 A 1.05 ISOPLUS247TMIXFR 10N100F 1000 V 9 A 1.20 F-Class: MegaHertz Switching trr 250 ns (Electrically Isolated Back Surface)N-Channel Enhancement ModeAvalanche Rated, High dV/dtLow Gate Charge and CapacitancesPreliminary Data SheetSymbol

0.15. ixgh12n100a.pdf Size:34K _ixys

VCES IC25 VCE(sat)Low VCE(sat) IGBTHigh Speed IGBTIXGH 12N100 1000 V 24 A 3.5 VIXGH 12N100A 1000 V 24 A 4.0 VSymbol Test Conditions Maximum Ratings TO-247ADVCES TJ = 25C to 150C 1000 VVCGR TJ = 25C to 150C; RGE = 1 MW 1000 VVGES Continuous 20 VC (TAB)GCVGEM Transient 30 VEIC25 TC = 25C24 AG = Gate C = CollectorIC90 TC = 90C12 AE = Emitter TAB =

0.16. ixgh12n100u1.pdf Size:119K _ixys

VCES IC25 VCE(sat)Low VCE(sat) IGBT with DiodeHigh Speed IGBT with DiodeIXGH 12N100U1 1000 V 24 A 3.5 VCombi Pack IXGH 12N100AU1 1000 V 24 A 4.0 VSymbol Test Conditions Maximum RatingsTO-247ADVCES TJ = 25C to 150C 1000 VVCGR TJ = 25C to 150C; RGE = 1 MW 1000 VVGES Continuous 20 VVGEM Transient 30 VC (TAB)GCIC25 TC = 25C24 AEIC90 TC = 90C12 AICM

0.17. ixft12n100qhv.pdf Size:148K _ixys

Advance Technical InformationHigh Voltage HiPerFETTMVDSS = 1000VIXFT12N100QHVPower MOSFETID25 = 12A Q-CLASS RDS(on) 1.05 N-Channel Enhancement ModeFast Intrinsic DiodeTO-268SGSymbol Test Conditions Maximum RatingsSVDSS TJ = 25C to 150C 1000 VD (Tab)VDGR TJ = 25C to 150C, RGS = 1M 1000 VVGSS Continuous 20 VG = Ga

0.18. ixft12n100q ixfh12n100q ixft10n100q ixfh10n100q.pdf Size:144K _ixys

VDSS ID25 RDS(on)HiPerFETTMIXFH/IXFT12N100Q 1000 V 12 A 1.05 Power MOSFETsIXFH/IXFT10N100Q 1000 V 10 A 1.20 Q Class trr 250 ns N-Channel Enhancement ModeAvalanche RatedLow Qg, High dv/dtSymbol Test Conditions Maximum Ratings TO-247 AD (IXFH)VDSS TJ = 25C to 150C 1000 VVDGR TJ = 25C to 150C; RGS

0.19. ixga12n100u1 ixgp12n100u1 ixga12n100au1 ixgp12n100au1.pdf Size:116K _ixys

0.20. ixft10n100 ixft12n100.pdf Size:556K _ixys

VDSS ID25 RDS(on)HiPerFETTMIXFT 10 N100 1000 V 10 A 1.20 Power MOSFETsIXFT12 N100 1000 V 12 A 1.05 N-Channel Enhancement ModeHigh dv/dt, Low trr, HDMOSTM Family trr 250 ns Preliminary data sheetSymbol Test Conditions Maximum Ratings TO-268 Case StyleVDSS TJ = 25C to 150C 1000 VVDGR TJ = 25C to 150

0.21. ixfh10n100 ixfm10n100 ixfh12n100 ixfm12n100.pdf Size:570K _ixys

VDSS ID25 RDS(on)HiPerFETTMIXFH/IXFM 10 N100 1000 V 10 A 1.20 Power MOSFETsIXFH/IXFM 12 N100 1000 V 12 A 1.05 N-Channel Enhancement Mode 250 ns High dv/dt, Low trr, HDMOSTM Family trr Symbol Test Conditions Maximum Ratings TO-247 AD (IXFH)VDSS TJ = 25C to 150C 1000 VVDGR TJ = 25C to 150C; RGS = 1 M

0.22. ixgp12n100.pdf Size:50K _ixys

0.23. ixgh12n100 ixgh12n100a.pdf Size:35K _ixys

0.24. ixgp12n100u1.pdf Size:84K _ixys

0.25. ixth10n100 ixtm10n100 ixth12n100 ixtm12n100.pdf Size:105K _ixys

VDSS ID25 RDS(on)MegaMOSTMFET IXTH / IXTM 10N100 1000 V 10 A 1.20 IXTH / IXTM 12N100 1000 V 12 A 1.05 N-Channel Enhancement ModeSymbol Test Conditions Maximum Ratings TO-247 AD (IXTH)VDSS TJ = 25C to 150C 1000 VVDGR TJ = 25C to 150C; RGS = 1 M 1000 VVGS Continuous 20 V D (TAB)VGSM Transient 30 VID25 TC = 25C 10N

0.26. ixgh12n100au1.pdf Size:119K _ixys

0.27. ixgp12n100a.pdf Size:50K _ixys

Mosfet 1000v 10a

0.28. ixgh12n100.pdf Size:34K _ixys

0.29. ntd12n10g ntd12n10t4.pdf Size:155K _onsemi

NTD12N10Power MOSFET12 Amps, 100 VoltsN-Channel Enhancement-Mode DPAKhttp://onsemi.comFeatures Source-to-Drain Diode Recovery Time Comparable to a DiscreteV(BR)DSS RDS(on) TYP ID MAXFast Recovery Diode100 V 165 mW @ 10 V 12 A Avalanche Energy Specified IDSS and RDS(on) Specified at Elevated TemperatureN-Channel Mounting Information Provided for the DPAK Pac

0.30. ntd12n10.pdf Size:158K _onsemi

Mosfet 1000v 100a

0.31. 12n10.pdf Size:224K _utc

UNISONIC TECHNOLOGIES CO., LTD 12N10 Power MOSFET 12A, 100V N-CHANNEL POWER MOSFET DESCRIPTION The UTC 12N10 is an N-channel mode power MOSFET usingUTCs advanced technology to provide customers with minimum on-state resistance for extremely high dense cell design, rugged avalanche characteristics and less critical alignment steps. FEATURES * RDS(on)

0.32. ut12n10.pdf Size:145K _utc

UNISONIC TECHNOLOGIES CO., LTD UT12N10 Preliminary Power MOSFET 12 Amps, 100 Volts N-CHANNEL POWER MOSFET 1 DESCRIPTION TO-251The UTC UT12N10 is an N-channel mode Power FET using UTCs advanced technology to provide custumers with minimum on-state resistance by extremely high dense cell design. Moreover, it s good at handing high power and current. 1 FEATURES

0.33. ceu12n10l ced12n10l.pdf Size:571K _cet

CED12N10L/CEU12N10LN-Channel Enhancement Mode Field Effect TransistorFEATURES100V, 11A, RDS(ON) = 175m @VGS = 10V. RDS(ON) = 185m @VGS = 5V.Super high dense cell design for extremely low RDS(ON).High power and current handing capability. DLead free product is acquired.TO-251 & TO-252 package.GDGSCEU SERIESCED SERIESSTO-252(D-PAK)TO-251(I-PAK)ABSOLUTE MA

0.34. ceu12n10 ced12n10.pdf Size:410K _cet

CED12N10/CEU12N10N-Channel Enhancement Mode Field Effect TransistorFEATURES100V, 11A, RDS(ON) = 180m @VGS = 10V.Super high dense cell design for extremely low RDS(ON).High power and current handing capability.DLead free product is acquired.TO-251 & TO-252 package.GDGSCEU SERIESCED SERIESSTO-252(D-PAK)TO-251(I-PAK)ABSOLUTE MAXIMUM RATINGS Tc = 25 C unless o

0.35. sdf12n100.pdf Size:155K _solitron

0.36. cs12n10.pdf Size:124K _china

CS12N10 N PD TC=25 75 W 0.6 W/ ID VGS=10V,TC=25 12 A IDM 30 A VGS 20 V Tjm +150 Tstg -55 +150 RthJC 1.25 /W BVDSS VGS=0V,ID=0.25mA 100 V RDS on VGS=10V,ID=45A 0.18 VGS th VDS=VGS,ID=0.25mA

0.37. ftk12n10s.pdf Size:362K _first_silicon

SEMICONDUCTOR FTK12N10STECHNICAL DATAN-Channel Power MOSFETDESCRIPTION SOP-8The device uses advanced trench technology and design to provide excellent RDS(ON) with low gate charge. It can be used in a wide variety of applications. FEATURESDD D D Green Device Available 8 6 5 7 Special process technology for high ESD capability High density cell design for ul

0.38. chm12n10pagp.pdf Size:47K _chenmko

CHENMKO ENTERPRISE CO.,LTDCHM12N10PAGPSURFACE MOUNT N-Channel Enhancement Mode Field Effect Transistor VOLTAGE 100 Volts CURRENT 11 AmpereAPPLICATION* Servo motor control. * Power MOSFET gate drivers.* Other switching applications.D-PAK(TO-252)FEATURE* Small package. (TO-252)* Super high dense cell design for extremely low RDS(ON). .094 (2.40).280 (7.10)* High powe

0.39. wvm12n10.pdf Size:23K _shaanxi

Shaanxi Qunli Electric Co., Ltd Add.:No. 1 Qunli Road,Baoji City,Shaanxi,China WVM12N10(MTM12N10) Power MOSFET(N-channel) TransistorFeatures: 1. Its voltage control component with good input impedance, small starting power dissipation, wide area of safe operation, good temperature stability. 2. Implementation of standards: QZJ840611 3. Use for high speed switch, circuit of powe

0.40. st12n10d.pdf Size:572K _stansontech

ST12N10D N Channel Enhancement Mode MOSFET 12.0A DESCRIPTION ST12N10D is the N-Channel logic enhancement mode power field effect transistor which is produced using high cell density, DMOS trench technology. The ST12N10D has been designed specially to improve the overall efficiency of DC/DC converters using either synchronous or conventional switching PWM controllers. It has been

Другие MOSFET... 2N7002LL, 2N7002Z, 2N7002ZT, UF3055, UTD3055, 12N06, 12N06Z, 15N06, IRF9540N, 15N20, 19N10, 22N20, 25N06, 25N10, 30N06, 50N06, 60N06.
